Sale Status
FOR SALE
MAKE
WHACHEON
MODEL
HL- 580 Gap Bed
In-page Image(s)
SWING
23 inch
CENTERS
60 or 80 inch
MOTOR
10 hp 220/440 volts 3 phase SPINDLE
SPINDLE
D-1-8 Camlock 3 1/8 inch hole diameter
SPEEDS
(12) 28 - 1,350 rpm
THREADS
Inch, metric - D. P. threads - module
TAIL STOCK
# 5 morse taper
DIMENSIONS
48" W x 149" L x 48" H
WEIGHT
7,500 lbs
OPTIONAL TOOLING:
Steady Rest, Carriage Stop, Coolant, Face Plate, Drive Plate, 4 way.
OPTIONAL TOOLING:
Oversize Steady Rest (6 - 12 inch), Rear Tool Post, Taper Attachment, Follow Rest, Chucks, Collet Closers, DRO, Quick Change Toolholder.
One Year Parts Warranty
